Projection System: 3LCD Technology, RGB liquid crystal shutter
LCD Panel: 1,04 inch with C2 Fine
Color Light Output: 8.000 Lumen- 5.600 Lumen (economy) In accordance with IDMS15.4
White Light Output: 8.000 Lumen - 5.600 Lumen (economy) In accordance with ISO 21118:2020
Portrait Colour Light Output: 8.000 lm
Portrait White Light Output: 8.000 lm
Resolution: 4K 3840 x 2160, 8.3m pixels, 16:9
Aspect Ratio: 16:9
Contrast Ratio: Over 5.000.000 : 1
Native Contrast: 3.000 : 1
Light source: Laser
Laser Light source: 20.000 hours Durability High, 30.000 hours Durability Eco
Keystone Correction: Manual vertical: ± 45 °, Manual horizontal ± 30 °
Colour Video Processing: 10 Bits
Colour Reproduction: Upto 1.07 billion colours
HDR support: HDR10, HLG
Throw Ratio: 0,34 - 7,16:1
Zoom: Motorized
Lens: Optical
Lens Shift: varies by lens
Screen Size: varies by lens
Projection Distance Wide: varies by lens
Projection Distance Tele: varies by lens
Projection Distance Wide/Tele: varies by lens
Projection Lens F Number: varies by lens
Projection Lens Focal Length: varies by lens
Projection Lens Focus: Motorized
Offset: varies by lens
Interchangeable Lens: Yes
Standard Lens: Not included
Interfaces: USB 2.0-A (2x), USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n (optional), HDMI in (2x), HDMI out, HDBaseT, Jack plug out, Near Field Communication (NFC), USB content playback, Remote
Network Protocol: HTTPS, IPv6, SNMP, ESC/VP.net, PJLink
Security: Kensington lock, Control panel lock, Padlock, Wireless LAN unit lock, Wireless LAN security, Password protection
Other features: 21:9 aspect ratio support, A/V mute, Auto Power On, Auto source search, Direct Power on/off, Edge Blending, Frame interpolation, Freeze image, Horizontal and vertical keystone correction, Lens position memory, Long light source life, OSD copy function, Point correction, Quick Corner, Schedule Function, Web Control, Wireless LAN capable, iProjection App
Video Color Modes: Cinema, Dynamic, Natural, Presentation, DICOM SIM, Multi Projection, BT709
Projector control: via: Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery
Power consumption: 453 Watt (Normal On-Mode), 502 Watt (Normal Peak-mode), 410 Watt (Eco Peak-Mode), 0,5 Watt (Energy saving standby)
Heat Dissipation: 1.707 BTU/hour (max)
Supply Voltage: AC 100 V - 240 V, 50 Hz - 60 Hz
Product dimensions: 545 x 436 x 189 mm (Width x Depth x Height)
Product weight: 18,6 kg
Noise Level: Normal: 35 dB (A) - Economy: 29 dB (A)
Supported Temperature: Storage -10° C - 60° C
Supported Humidity: Operation 20% - 80%, Storage 10% - 90%
Included Software: Epson Creative Projection, Epson Projector Config Tool, Epson Projector Content Manager, Epson Projector Management, Epson Projector Professional Tool
Options: Air filter, Camera module, Ceiling mount, Wireless LAN unit
Room Type / Application: Boardroom, Large Meeting Room / Auditorium, Meeting room / Classroom, Projection Mapping, Rental / Staging, Signage / Retail, Visitor Attraction
Positioning: Ceiling Mounted, Desktop, Floor, Flying Frame, Table Mounted, Wall Mounted
Colour: White
Warranty: 36 months Carry in
- Lens - ELPLU04 - Short throw off axis 2 - EB-PU Series (V12H004U04)
- Lens - ELPLW05 - Wide zoom 1 - EB-PU Series (V12H004W05)
- Lens - ELPLW06 - Wide zoom 2 - EB-PU Series (V12H004W06)
- Lens - ELPLL08 - Long throw - EB-PU Series (V12H004L08)
- Lens - ELPLM11 - Mid throw 4 - EB-PU Series (V12H004M0B)
- Lens - ELPLM10 - Mid throw 3 - EB-PU Series (V12H004M0A)
- Lens - ELPLM15 - Mid throw - EB-PU Series (V12H004M0F)
- Lens - ELPLW08 - Wide throw - EB-PU2000 Series (V12H004W08)
- Lens - ELPLU03S - Short throw off axis 1 - EB-PU Series (V12H004UA3)
- Lens - ELPLX02S - UST - EB-PU2000 Series (V12H004X0B)
- Camera Unit - ELPEC01 (V12HA46010)
- Adapter - ELPAP11 Wireless LAN (5GHz) (V12H005A01)
- Stacking Frame - ELPMB59 - EB-PU2200 Series (EVO) (V12H996B59)
- Ceiling Mount - ELPMB68 (V12H006AE0)
- Stacking Frame - ELPMB84 - EB-PU2200 Series (V12H006AW0)
- Tilt Adaptor - ELPMB81 - EB-PU Series (V12H006AT0)
- Rail Adaptor - ELPMB85 - EB-PU Series (V12H006AX0)
- Portrait Adaptor - ELPMB78 - EB-PU Series (V12H006AQ0)
- Air Filter - ELPAF46 (V13H134A46)
- External Air Filter - ELPAF63 - EB-PU1000 Series (V13H134AD0)
