Duration and temperature can easily be adjusted and monitored using the digital controller.
Variable work pressure
The work pressure is easy to adjust - in each case matching the transfer object and procedure.
Interchangeable base plates available - also in combination with a quick-change system
The safety and quality of this device is constantly monitored - according to German safety standards.
Precise temperature distribution
The high-quality heat plate ensures an exact temperature distribution over the entire heating surface.
A state-of-the-art controller reduces the temperature fluctuations to a minimum, thus ensuring consistently good transfer results.
Two work plates
with the 2 base plates, high production volumes can easily be achieved
The heat press automatically opens after the set time has elapsed.
|working area||2 x 40cm x 50cm|
|scope of delivery||heat press, power cord, compressor valve, manual|
|pressure setting||setting of pneumatic pressure|
|max. downforce||350 g/cm²|
|max temperature||225 °C|
|maximum time preset||999 s|
|power supply||AC 230V / 50Hz - 60Hz, 1.8kW|
|environment||+5°C - +35°C / 30% - 70% relative humidity|
|weight without packaging||88,00 kg|
|weight with package||115,88 kg|
