Precise temperature distribution
The high-quality heat plate ensures an exact temperature distribution over the entire heating surface.
Large workspace
The press can be opened over 110°, thus guaranteeing relaxed and safe working.
Opens automatically
The heat press automatically opens after the set time has elapsed.
Hardly any heat marks and dye migration
Heat marks on the garments are mostly prevented because only the absolutely necessary part is heated. By doing so, the garment is also protected from resublimation and dye migration.
Toner transfer
Better printing results, especially with sublimation and white toner transfers.
Low hysteresis
A state-of-the-art controller reduces the temperature fluctuations to a minimum, thus ensuring consistently good transfer results.
Replaceable plates
Interchangeable base plates available - also in combination with a quick-change system
Safe working
The safety and quality of this device is constantly monitored - according to German safety standards.
Variable work pressure
The work pressure is easy to adjust - in each case matching the transfer object and procedure.
Digital Controllers
Time and temperature can easily be set and controlled by the digital controllers.
Secabo Smart Transfer App
The device is ready for control via the Secabo app. With the aid of this app, suitable transfer parameters can be selected for your application.
Bluetooth interface
The device can be connected and controlled via Bluetooth with a mobile device and the Secabo Smart Transfer App.
Technical Data
| Size of the work surfaces | 40x50cm (HP7), 35x45cm (SH7) and 40x50cm (TB7) |
| Adjustment path of the max. Object height | 70mm |
| swivel angle | 110°, opening to the right or left possible |
| max temperature | 225 °C (HP7), 190 °C (SH7) and 160 °C (TB7) |
| max. downforce | 250 g/ cm² (HP7) and 360 g/cm² (SH7) |
| maximum time preset | 999 s (TS7 SMART) |
| Power supply: | AC voltage 230V / 50Hz - 60Hz, 2 kW (TS7 SMART), AC voltage 230V / 50Hz - 60Hz, 1.3kW (SH7) and AC voltage 230V / 50Hz - 60Hz, 2.0kW (TB7) |
| environment | + 5 ° C - + 35 C / 30% - 70% humidity (applies to all components) |
| dimensions | W: 596mm x D: 1070mm H: 854mm (TS7 SMART with stand) 41x54x8cm (SH7) and 41x51x7cm (TB7) |
| scope of delivery | Transfer press (TS7 SMART), SH7, TB7, HP7, quick-change system, power cable and German-language operating instructions |
| options | Removable plates and slide extension |
| Membrane life | The membrane is a wearing part. If you work with the Membrane correctly, you can expect it to have a lifespan of 25,000 transfers. |
| pressure setting | via height adjustment of the heating plate (TS7 SMART) and adjustment of pneumatic pressure 0-360 g/cm² (SH7) |
| Heating up time SH7 | 2.5min - 3min |
| weight without packaging | 64,00 kg |
| weight with package | 73,00 kg |
| Brand | Secabo |
